 SNH940U12.1W21三螺杆泵泵头安装尺寸图
|
|
|
|
|
SNH940U12.1W21三螺杆泵简介工作原理:SN三螺杆泵是无脉动轴向输送具有一定润滑性介质的定量容积式低压转子泵，适于输送燃料油、润滑油、液压油、矿物油等油类和具有润滑性的流动性液体。
所输送的介质中不得含有任何磨料颗粒和对泵材料有腐蚀的物质。
SNH940U12. 1 introduction of w21 three screw pump working principle: SN three
screw pump is a pulsating axial transmission has a certain quantitative displacement
of lubricity medium low pressure rotor pump, suitable for conveying fuel oil,
lubricating oil, hydraulic oil, mineral oil, such as oil and has the lubricity
of liquid liquid. The conveying medium shall not contain any abrasive particles
and the pump material material corrosion.
SNH940U12.1W21三螺杆泵: 由特殊型线（摆线）构成的螺旋型面，当电机或马达驱动主动螺杆转动时，其不断运动的各个密封腔室逐渐形成真空，液体在大气压的作用下由吸入口吸入并沿轴向连续、无脉动的输送到排出口，无搅拌、乳化现象。形成排出压力的能力取决于系统负载和螺杆密封腔的数量，同时也与输送介质的粘度以及驱动转速也有一定的关系。
SNH940U12. 1 w21 three screw pump: made of special type line (cycloid) spiral
surface, when the motor or motor drive screw rotates, the constant motion of
the sealing chamber gradually formed a vacuum, the liquid under the action of
atmospheric pressure by suction suction along the axial continuous, pulseless
to discharge, without stirring, emulsifying phenomenon.Form the exhaust pressure
depends on the ability of system load and the number of screw seal cavity, at
the same time, also with the medium viscosity and driving speed also have certain
relations.
特点 SN三螺杆泵 1.转子液压平衡，振动小，噪音低。 2.输出稳定，无脉动。 3.高效率。 4.具有很强的自吸能力。
5.零部件采用通用性强的系列化设计，具有多种安装方式。 6.结构紧凑，体积小，重量轻，可在较高转速下工作 输送介质种类 a.润滑性液体：如机械油，滑油，重油，渣油
b.低润滑性液体：如轻柴油，重柴油，含蜡稀油 c.粘性液体：如各种合成橡胶液和人造胶液，乳化液 Characteristics of SN three screw
pump (1) the rotor hydraulic balance, little vibration, low noise.2. The output
is stable, no pulsation.3. High efficiency.4. Has a strong self-priming capacity.5.
Parts versatility of seriation design, with a variety of installation.6. Compact
structure, small volume, light weight, can work under high speed transmission
medium type a. lubricity liquid, such as machine oil, lubricating oil, heavy
oil, residual oil b. low lubricity liquid: such as light diesel oil, heavy diesel
oil, wax containing thin oil c. viscous liquid, such as various kinds of synthetic
rubber and synthetic rubber, emulsion
