 船舶电站柴油机自动预热供油泵
我公司生产的kcb齿轮泵,2cy齿轮泵,ycb圆弧齿轮泵,单螺杆泵,双螺杆泵和三螺杆泵都通过了中国船级社CCS船检认证.我公司所有的泵型都可以用在船舶电站用作供油泵,使用哪个泵需要根据客户所需供油泵的压力和流量觉得选择什么型号的泵.Our
company produces the KCB gear pump, 2 cy gear pump, ycb arc gear pump, single
screw pump, double screw pump and the three screw pump has passed the certification
of China classification society CCS classification survey. My company all type
pump can be used in ship power station is used as for the oil pump, which pump
need according to the customer required for pressure and flow of oil pump think
to choose what type of pump.
kcb供油泵泵参数表:
型号 Model
| 流量
| 工作压力
Mpa
| 吸入真空高度m
| 进出口口径mm
| 转速
Nr/min
| 电机功率
kw |
m 3 /h
| L/min |
|
| 1.1
| 18.3
| 1.45
| 5
| G 3 / 4 "
| 1400
| 1.5 |
|
| 2
| 33.3
| 1.45
| 5
| G 3 / 4 "
| 1420
| 2.2 |
|
| 3.3
| 55
| 0.33
| 5
| G1"
| 1400
| 1.5 |
KCB-83.3
| 5
| 83.3
| 0.33
| 5
| G 1 / 2 "
| 1420
| 2.2 |
KCB-135
| 8
| 135
| 0.33
| 3
| Φ50
| 1440
| 4 |
KCB-200
| 12
| 200
| 0.33
| 3
| Φ50
| 1440
| 4 |
KCB-300
| 18
| 300
| 0.36
| 3
| Φ70
| 960
| 5.5 |
|
| 29
| 483.3
| 0.36
| 3
| Φ70
| 1440
| 7.5 |
|
| 38
| 633
| 0.28
| 3
| Φ100
| 970
| 11 |
KCB-960
| 58
| 960
| 0.28
| 3
| Φ100
| 1470
| 18.5 |
KCB-1200
| 72
| 1200
| 0.28
| 2
| Φ150
| 740
| 37 |
|
| 96
| 1600
| 0.28
| 2
| Φ150
| 980
| 45 |
KCB-1800
| 110
| 1800
| 0.28
| 2
| Φ200
| 740
| 55 |
KCB-2500
| 150
| 2500
| 0.28
| 2
| Φ200
| 980
| 75 |
KCB-3800
| 230
| 3800
| 0.28
| 2
| Φ250
| 990
| 110 |
KCB-5400
| 325
| 5400
| 0.28
| 2
| Φ250
| 990
| 110 |
2.2CY供油泵参数表
型号 Model
| 流量
| 排出压力 Mpa
| 吸入真空高度m
| 进出口口径mm
| 转速
Nr/min
| 电机功率Power kw |
m 3 /h
| L/min |
2CY-0.6
| 0.6
| 10
| 0.6/2.5
| 3
| G3/4"
| 1400
| 1.1/1.5 |
2CY-1.08
| 1.08
| 18
| 0.6/2.5
| 3
| G3/4"
| 1400
| 1.5 |
2CY-2.1
| 2.1
| 35
| 0.6/2.5
| 3
| C1"
| 1420
| 1.5/3 |
2CY-3
| 3
| 50
| 0.6/2.5
| 3
| C1"
| 1420/1440
| 2.2/4 |
2CY-4.2
| 4.2
| 70
| 0.6/2.5
| 3
| G11/4"
| 1440
| 4/5.5 |
2CY-7.5
| 7.5
| 125
| 0.6/2.5
| 3
| G11/2"
| 1440
| 5.5/7.5 |
2CY-10
| 10
| 167
| 0.6/2.5
| 3
| G11/2"
| 1440/1460
| 7.5/11 |
2CY-12
| 12
| 200
| 0.6/2.5
| 3
| G2"
| 1460
| 7.5/11 |
2CY-15
| 15
| 250
| 0.6/2.5
| 3
| G2.5"
| 1440/1460
| 7.5/15 |
2CY-18
| 18
| 300
| 0.6/2.5
| 3
| G2.5"
| 1440/1470
| 7.5/18.5 |
3.YCB供油泵参数表:
型号 Model
| 流量Flow Capacity
| 工作压力
Mpa
| 吸入真空高度
m
| 进出口口径
mm
| 效率
%
| 转速
Nr/min
| 电机功率
kw |
m3/h
| L/m |
YCB 0.6/0.6
| 0.6
| 10
| 0.6
| 3
| Φ25
| 32
| 910
| 0.75 |
YCB 1.0/0.6
| 1.0
| 16.7
| 0.6
| 3
| Φ25
| 32
| 1390
| 0.75 |
YCB 1.6/0.6
| 1.6
| 26.7
| 0.6
| 3
| Φ32
| 42
| 910
| 0.75 |
YCB 2.5/0.6
| 2.5
| 42
| 0.6
| 3
| Φ32
| 42
| 1400
| 1.1 |
YCB 3.3/0.6
| 3.3
| 55
| 0.6
| 3
| Φ40
| 60
| 940
| 1.5 |
YCB 4/0.6
| 4
| 66
| 0.6
| 3
| Φ50
| 60
| 940
| 1.5 |
YCB 5/0.6
| 5
| 83.3
| 0.6
| 3
| Φ40
| 60
| 1420
| 2.2 |
YCB 6/0.6
| 6
| 100
| 0.6
| 3
| Φ50
| 60
| 1420
| 2.2 |
YCB 8/0.6
| 8
| 133
| 0.6
| 3
| Φ65
| 60
| 960
| 3 |
YCB 10/0.6
| 10
| 167
| 0.6
| 3
| Φ65
| 60
| 960
| 4 |
YCB 12/0.6
| 12
| 200
| 0.6
| 3
| Φ65
| 61
| 1440
| 5.5 |
YCB 15/0.6
| 15
| 250
| 0.6
| 3
| Φ65
| 61
| 1440
| 5.5 |
YCB 20/0.6
| 20
| 333
| 0.6
| 3
| Φ80
| 68
| 970
| 7.5 |
YCB 25/0.6
| 25
| 420
| 0.6
| 3
| Φ80
| 69
| 970
| 11 |
YCB 30/0.6
| 30
| 500
| 0.6
| 3
| Φ100
| 70
| 970
| 11 |
YCB 40/0.6
| 40
| 660
| 0.6
| 3
| Φ125
| 72
| 970
| 15 |
不同形式的供油泵有不同的结构,所以客户在选型的时候,如有不名之处请联系我公司,我公司将详细的为您解答所有关于供油泵的知识.Different
forms of supply pump has different structure, so customers in the selection,
please contact me if there is any don't name the company, my company will be
detailed answers to all knowledge about supply pump for you.
